Art.nr. Ø Inwendig (mm) Wanddikte (mm) Werkdruk (bar) Max Vacuüm (bar) Buigradius (mm) Rollengte (m) Gewicht (kg/m) Bestellen
30245020032 32 1,4 3,0 0,90 48 5 of 10 0,38
30245020035 35 1,4 2,6 0,80 53 5 of 10 0,45
30245020040 40 1,4 2,3 0,70 60 5 of 10 0,56
30245020050 50 1,4 1,9 0,60 75 5 of 10 0,67
30245020060 60 1,4 1,8 0,55 90 5 of 10 0,79
30245020075 75 1,4 1,2 0,50 113 5 of 10 0,98
30245020080 80 1,4 1,2 0,45 120 5 of 10 1,09
30245020090 90 1,4 1,1 0,45 135 5 of 10 1,23
30245020100 100 1,4 1,1 0,40 150 5 of 10 1,36
30245020110 110 1,4 1,1 0,35 165 5 of 10 1,38
30245020120 120 1,4 0,9 0,30 180 5 of 10 1,42
30245020125 125 1,4 0,8 0,25 188 5 of 10 1,54
30245020140 140 1,4 0,7 0,20 210 5 of 10 1,75
30245020150 150 1,4 0,7 0,20 225 5 of 10 1,82
30245020160 160 1,4 0,6 0,20 240 5 of 10 2,15
30245020180 180 1,4 0,5 0,15 270 5 of 10 2,55
30245020200 200 1,4 0,5 0,15 300 5 of 10 2,92
30245020225 225 1,4 0,4 0,10 338 5 of 10 3,25
30245020250 250 1,4 0,3 0,10 375 5 of 10 3,57
30245020300 300 1,4 0,3 0,10 450 5 of 10 4,31
ATEX PU slangen op aanvraag.
