Art.nr. | Type | Aantal tanden | Klembus | Max. boring (9mm) | Gewicht (kg) | Bestellen |
---|---|---|---|---|---|---|
800450021315 | 42-15 | 15 | 1008 | 25 | 0,25 | |
800450021317 | 42-17 | 17 | 1210 | 32 | 0,35 | |
800450021318 | 42-18 | 18 | 1210 | 32 | 0,38 | |
800450021319 | 42-19 | 19 | 1210 | 32 | 0,40 | |
800450021321 | 42-21 | 21 | 1610 | 42 | 0,45 | |
800450021322 | 42-22 | 22 | 1610 | 42 | 0,55 | |
800450021323 | 42-23 | 23 | 1610 | 42 | 0,65 | |
800450021325 | 42-25 | 25 | 2012 | 50 | 0,80 | |
800450021330 | 42-30 | 30 | 2012 | 50 | 1,50 | |
800450021338 | 42-38 | 38 | 2012 | 50 | 2,70 | |
800450021345 | 42-45 | 45 | 2012 | 50 | - | |
800450021376 | 42-76 | 76 | 2012 | 50 | 6,00 |
Art.nr. | Type | Aantal tanden | Klembus | Max. boring (9mm) | Gewicht (kg) | Bestellen |
---|---|---|---|---|---|---|
800450021616 | 52-16 | 16 | 1610 | 42 | 1,00 | |
800450021617 | 52-17 | 17 | 1610 | 42 | 1,11 | |
800450021621 | 52-21 | 21 | 1610 | 42 | 1,84 | |
800450021623 | 52-23 | 23 | 1610 | 42 | 2,41 | |
800450021625 | 52-25 | 25 | 2012 | 50 | 2,55 | |
800450021657 | 52-57 | 57 | - | - | - |
Art.nr. | Type | Aantal tanden | Klembus | Max. boring (9mm) | Gewicht (kg) | Bestellen |
---|---|---|---|---|---|---|
800450021915 | 62-15 | 15 | 1610 | 42 | 0,75 | |
800450021917 | 62-17 | 17 | 1610 | 42 | 0,95 | |
800450021919 | 62-19 | 19 | 2012 | 50 | 1,15 | |
800450021921 | 62-21 | 21 | 2517 | 60 | 1,20 | |
800450021923 | 62-23 | 23 | 2517 | 60 | 2,00 | |
800450021925 | 62-25 | 25 | 2517 | 60 | 3,08 | |
800450021927 | 62-27 | 27 | 2517 | 60 | 3,36 | |
800450021930 | 62-30 | 30 | 2517 | 60 | 4,20 | |
800450021938 | 62-38 | 38 | 3020 | 75 | 6,50 | |
800450021945 | 62-45 | 45 | 3020 | 75 | 8,25 | |
800450021957 | 62-57 | 57 | 3020 | 75 | 10,00 | |
800450021976 | 62-76 | 76 | 3020 | 75 | 16,00 |
Art.nr. | Type | Aantal tanden | Klembus | Max. boring (9mm) | Gewicht (kg) | Bestellen |
---|---|---|---|---|---|---|
800450022515 | 82-15 | 15 | 2012 | 50 | 2,20 | |
800450022517 | 82-17 | 17 | 2517 | 60 | 2,60 | |
800450022519 | 82-19 | 19 | 2517 | 60 | 3,00 | |
800450022521 | 82-21 | 21 | 3020 | 75 | 3,00 | |
800450022523 | 82-23 | 23 | 3020 | 75 | 5,85 | |
800450022525 | 82-25 | 25 | 3020 | 75 | 6,80 | |
800450022526 | 82-26 | 26 | 3020 | 75 | 7,39 | |
800450022527 | 82-27 | 27 | 3020 | 75 | 7,98 | |
800450022528 | 82-28 | 28 | 3020 | 75 | 8,57 | |
800450022530 | 82-30 | 30 | 3030 | 75 | 9,75 | |
800450022538 | 82-38 | 38 | 3030 | 75 | 14,50 | |
800450022545 | 82-45 | 45 | 3030 | 75 | 20,75 | |
800450022557 | 82-57 | 57 | 3535 | 90 | 27,00 | |
800450022595 | 82-95 | 95 | 4040 | 100 | 56,60 |
Art.nr. | Type | Aantal tanden | Klembus | Max. boring (9mm) | Gewicht (kg) | Bestellen |
---|---|---|---|---|---|---|
800450023215 | 102-15 | 15 | 3020 | 75 | 3,44 | |
800450023217 | 102-17 | 17 | 3020 | 75 | 6,87 | |
800450023225 | 102-25 | 25 | 3030 | 75 | 20,90 | |
800450023238 | 102-38 | 38 | 3535 | 90 | 24,00 |
Art.nr. | Type | Aantal tanden | Klembus | Max. boring (9mm) | Gewicht (kg) | Bestellen |
---|---|---|---|---|---|---|
800450023821 | 122-21 | 21 | 3535 | 90 | 23,40 | |
800450023823 | 122-23 | 23 | 3535 | 90 | 29,40 | |
800450023825 | 122-25 | 25 | 4040 | 100 | 25,40 |
Type | Duplex |
Materiaal | Staal |
Uitvoering | volgens ISO R606 en DIN 8187 en 8180 |
