Selecteer een uitvoering
Art.nr. Steekcirkel Dw (mm) Klembus nr. Max. boring (mm) Gewicht (kg) Bestellen
800300010080 80 1210 32 0,55
800300010085 85 1210 32 0,68
800300010090 90 1210 32 0,68
800300010095 95 1210 32 0,79
800300010100 100 1610 42 0,79
800300010106 106 1610 42 0,90
800300010112 112 1610 42 1,00
800300010118 118 1610 42 1,20
800300010125 125 1610 42 1,30
800300010132 132 1610 42 1,60
800300010140 140 1610 42 1,70
800300010150 150 1610 42 1,20
800300010160 160 1610 42 1,80
800300010180 180 1610 42 2,10
800300010200 200 2012 50 2,90
800300010224 224 2012 50 3,50
800300010250 250 2012 50 3,90
800300010280 280 2012 50 4,40
800300010400 400 2012 50 6,60
Art.nr. Steekcirkel Dw (mm) Klembus nr. Max. boring (mm) Gewicht (kg) Bestellen
800300020050 50 - - -
800300020080 80 1210 32 0,62
800300020085 85 1210 32 0,76
800300020090 90 1610 42 0,91
800300020095 95 1610 42 0,85
800300020100 100 1610 42 0,94
800300020106 106 1610 42 1,10
800300020112 112 1610 42 1,30
800300020118 118 1610 42 1,50
800300020125 125 1610 42 1,70
800300020132 132 2012 50 2,10
800300020140 140 2012 50 2,50
800300020150 150 2012 50 2,90
800300020160 160 2012 50 3,30
800300020180 180 2012 50 4,80
800300020200 200 2517 60 5,00
800300020224 224 2517 60 5,30
800300020250 250 2517 60 5,60
800300020280 280 2517 60 6,40
800300020315 315 2517 60 7,20
800300020355 355 2012 50 -
800300020400 400 2517 60 10,80
800300020500 500 3020 75 19,80
800300020630 630 3020 75 20,80
Art.nr. Steekcirkel Dw (mm) Klembus nr. Max. boring (mm) Gewicht (kg) Bestellen
800300030080 80 1210 32 0,83
800300030090 90 1610 42 0,99
800300030100 100 1610 42 1,25
800300030106 106 1610 42 1,30
800300030112 112 2012 50 1,40
800300030118 118 2012 50 1,60
800300030125 125 2012 50 1,80
800300030132 132 2012 50 2,20
800300030140 140 2517 60 2,70
800300030150 150 2517 60 3,90
800300030160 160 2517 60 4,10
800300030180 180 2517 60 5,70
800300030200 200 2517 60 6,90
800300030224 224 2517 60 7,00
800300030250 250 2517 60 7,10
800300030280 280 2517 60 10,80
800300030315 315 3020 75 13,60
800300030355 355 - - -
800300030400 400 3020 75 14,50
800300030500 500 3020 75 19,80
800300030800 800 3525 100 42,00
Art.nr. Steekcirkel Dw (mm) Klembus nr. Max. boring (mm) Gewicht (kg) Bestellen
800300040090 90 1610 42 1,30
800300040100 100 1610 42 1,70
800300040106 106 2012 50 1,80
800300040112 112 2012 50 1,90
800300040118 118 2012 50 2,20
800300040125 125 2012 50 2,40
800300040132 132 2012 60 2,90
800300040140 140 2517 60 3,20
800300040150 150 2517 60 4,10
800300040160 160 2517 60 4,70
800300040170 170 - - -
800300040180 180 2517 60 6,30
800300040200 200 3020 75 7,80
800300040224 224 3020 75 8,80
800300040250 250 3020 75 9,70
800300040280 280 3020 75 12,20
800300040315 315 3020 75 14,50
800300040355 355 - - -
800300040400 400 3020 75 16,30
800300040450 450 - - -
800300040500 500 3020 75 24,30
800300040630 630 3525 100 36,20
Art.nr. Steekcirkel Dw (mm) Klembus nr. Max. boring (mm) Gewicht (kg) Bestellen
800300050090 90 - - -
800300050100 100 1610 42 2,00
800300050106 106 2012 50 2,10
800300050118 118 2012 60 2,50
800300050125 125 2012 50 2,80
800300050140 140 2517 60 3,60
800300050150 150 2517 60 4,40
800300050160 160 2517 60 5,20
800300050180 180 3020 75 6,40
800300050224 224 3020 75 9,70
800300050250 250 3020 75 10,80
800300050315 315 3525 100 19,90
800300050500 500 3525 100 39,70
800300050630 630 3525 100 42,10
Art.nr. Steekcirkel Dw (mm) Klembus nr. Max. boring (mm) Gewicht (kg) Bestellen
800300060118 118 2012 50 2,80
800300060125 125 2012 50 3,20
800300060140 140 2517 60 4,10
800300060180 180 3020 75 7,00
800300060200 200 3020 75 9,60
800300060400 400 3525 100 25,10
800300060500 500 3525 100 54,20
Zie Taper Lock klembussen
