Selecteer een uitvoering
Art.nr. Steekcirkel Dw (mm) Klembus nr. Max. boring (mm) Gewicht (kg) Bestellen
800330010056 56 1008 25 0,50
800330010060 60 1008 25 0,34
800330010063 63 1108 28 0,26
800330010067 67 1108 28 0,31
800330020071 71 1108 28 0,34
800330010075 75 1108 28 0,40
800330010080 80 1210 32 0,45
800330010085 85 1210 32 0,62
800330010090 90 1210 32 0,71
800330010095 95 1210 32 0,80
800330010100 100 1210 32 1,80
800330010106 106 1610 42 0,50
800330010112 112 1610 42 1,00
800330010118 118 1610 42 0,70
800330010125 125 1610 42 1,20
800330010132 132 1610 42 1,40
800330010140 140 1610 42 1,50
800330010150 150 1610 42 1,00
800330010180 180 1610 42 2,60
800330010200 200 2012 50 3,60
Art.nr. Steekcirkel Dw (mm) Klembus nr. Max. boring (mm) Gewicht (kg) Bestellen
800330020063 63 1108 28 0,26
800330020067 67 1108 28 0,34
800330020075 75 1210 32 0,43
800330020080 80 1210 32 0,48
800330020085 85 1610 42 0,52
800330020090 90 1610 42 0,60
800330020095 95 1610 42 0,71
800330020100 100 1610 42 0,79
800330020106 106 1610 42 0,60
800330020112 112 1610 42 1,10
800330020118 118 1610 42 1,20
800330020125 125 1610 42 1,60
800330020132 132 1610 42 1,80
800330020140 140 1610 42 2,10
800330020150 150 2012 50 2,00
800330020160 160 2012 50 3,10
800330020180 180 2012 50 4,10
800330020200 200 2012 50 3,30
800330020224 224 2012 50 3,10
800330020250 250 2012 50 4,50
800330020280 280 2012 50 4,90
800330020315 315 2012 50 5,50
800330020500 500 2517 60 16,80
Art.nr. Steekcirkel Dw (mm) Klembus nr. Max. boring (mm) Gewicht (kg) Bestellen
800330030063 63 1108 28 0,40
800330030075 75 1210 32 0,60
800330030080 80 1210 32 0,68
800330030085 85 1610 42 0,74
800330030090 90 1610 42 0,77
800330030095 95 1610 42 0,97
800330030100 100 1610 42 1,10
800330030106 106 1610 42 0,70
800330030118 118 2012 50 1,50
800330030125 125 2012 50 1,90
800330030132 132 2012 50 2,10
800330030140 140 2012 50 2,60
800330030150 150 2012 50 3,00
800330030160 160 2012 50 3,60
800330030180 180 2012 50 4,90
800330030200 200 2012 50 6,20
800330030224 224 2012 50 3,80
800330030250 250 2012 50 5,20
800330030315 315 2517 60 7,30
800330030355 355 2517 60 8,80
Art.nr. Steekcirkel Dw (mm) Klembus nr. Max. boring (mm) Gewicht (kg) Bestellen
800330040085 85 1610 42 0,97
800330040106 106 1610 42 0,80
800330040112 112 2012 50 1,60
800330040118 118 2012 50 2,00
800330040125 125 2012 50 2,20
800330040132 132 2012 50 2,40
800330040140 140 2012 50 2,90
800330040150 150 2517 60 3,50
800330040160 160 2517 60 4,30
800330040170 170 2517 60 4,30
800330040180 180 2517 60 6,10
800330040200 200 2517 60 7,90
800330040224 224 2517 60 4,60
800330040280 280 2517 60 7,80
800330040315 315 2517 60 8,90
800330040400 400 2517 60 12,20
800330040500 500 3020 75 19,00
Art.nr. Steekcirkel Dw (mm) Klembus nr. Max. boring (mm) Gewicht (kg) Bestellen
800330050085 85 1610 42 1,20
800330050090 90 1610 42 1,20
800330050095 95 1610 42 1,40
800330050100 100 2012 50 1,50
800330050106 106 2012 50 0,90
800330050118 118 2012 50 2,00
800330050125 125 2012 50 2,30
800330050132 132 2517 60 2,80
800330050140 140 2517 60 3,30
800330050150 150 2517 60 4,00
800330050160 160 2517 60 4,80
800330050250 250 2517 60 7,80
800330050315 315 2517 60 10,40
800330050500 500 3020 75 22,50
Art.nr. Steekcirkel Dw (mm) Klembus nr. Max. boring (mm) Gewicht (kg) Bestellen
800330060090 90 - - -
800330060100 100 - - -
800330060106 106 - - -
800330060132 132 2517 60 3,20
800330060140 140 2517 60 3,60
800330060150 150 2517 60 4,50
800330060180 180 2517 60 7,00
800330060200 200 2517 60 9,20
800330060250 250 2517 60 8,40
800330060500 500 3020 75 24,50
800330060630 630 3625 100 34,70
Zie Taper Lock klembussen
