Art.nr. Ø Inwendig (mm) Ø Uitwendig (mm) Werkdruk (bar) Max Vacuüm (bar) Buigradius (mm) Rollengte (m) Gewicht (kg/m) Bestellen
20406020010 10 16,0 7,0 0,85 20 60 0,18
20406020012 12 18,0 7,0 0,85 25 60 0,19
20406020014 14 20,0 6,0 0,85 30 60 0,20
20406020016 16 22,0 6,0 0,85 35 60 0,23
20406020018 18 24,5 6,0 0,85 75 60 0,28
20406020020 20 27,0 5,0 0,85 50 60 0,34
20406020022 22 29,0 5,0 0,85 55 60 0,36
20406020025 25 33,0 5,0 0,85 60 60 0,50
20406020030 30 39,0 4,5 0,85 70 60 0,60
20406020032 32 41,0 4,5 0,85 75 60 0,65
20406020035 35 44,0 4,0 0,85 80 60 0,75
20406020038 38 37,0 4,0 0,85 90 30 0,80
20406020040 40 49,5 3,0 0,85 95 30 0,87
20406020045 45 55,0 3,0 0,80 110 30 1,10
20406020050 50 60,0 3,0 0,80 125 30 1,20
20406020060 60 72,0 2,5 0,80 140 30 1,80
20406020065 63 77,0 2,0 0,80 150 30 2,35
20406020070 70 86,0 2,0 0,70 180 30 2,60
20406020075 75 84,0 2,0 0,70 200 30 2,50
20406020080 80 94,0 2,0 0,70 220 30 2,70
20406020090 90 107,0 3,0 0,70 260 30 3,80
20406020100 100 114,0 3,0 0,70 300 30 4,20
20406020110 110 128,0 3,0 0,90 320 20 4,70
20406020120 120 138,0 2,0 0,90 340 20 5,20
20406020125 125 144,0 2,0 0,90 350 20 5,40
20406020150 150 169,0 2,0 0,90 450 20 7,20
